Every job, vehicle and market is different, so a standard trailer is not always the right trailer. RISENMEGA builds custom trailers to your size, load and configuration: flatbed, box, cage, excavator, tipping and boat trailers. This guide shows what you can customize and how to send us a sketch that gets you an accurate quote.
Quick answer
- What can be customized: deck size, load rating, axles, ramps and gates, sides, running gear, coupler and jack, lighting and plugs, accessories, finish and packing.
- How to order: tell us what you carry, draw a simple dimensioned sketch, confirm your market's requirements, then review our drawing and quote.
- Starting points: a UTV flatbed at 3100 × 1600 mm and 1000 kg, and an ATV flatbed at 2300 × 1350 mm and 500 kg. Both can be resized.
The RISENMEGA custom trailer series
Our catalog is built around trailers that are made to order. These are the families you can start from.
Flatbed and utility trailers
Single-axle and tandem-axle flatbeds with checker-plate decks, side rails and rear ramp gates for ATVs, UTVs, mowers and general cargo.
Box and cage trailers
Galvanized box trailers with or without ramp, mesh ramp, full mesh sides, folding cage and tool box versions, in single or tandem axle.
Excavator and plant trailers
Tandem-axle trailers with upright loading ramps for mini excavators and compact machinery, sized around your machine.
Hydraulic tipping trailers
A tandem-axle cage trailer with a hydraulic tipping body for unloading bulk material.
Boat and jet ski trailers
Roller, slide-bar and treated-wood bunk layouts, from compact single-axle models to long triple-axle builds, plus jet ski trailers.
Special-purpose builds
Examples in our catalog include a fire tank trailer and a tool box trailer. Ask us if you have a niche use.
Browse ready-made models first: utility and flatbed trailers and equipment trailers. Then use this guide to change what you need.
What you can customize
Ten areas, from the big choices to the small ones that decide whether the trailer fits your job and your country.
| Area | Options |
|---|---|
| Deck size | Internal deck length and width, overall length and width. Standard UTV size is 3100 × 1600 mm; standard ATV size is 2300 × 1350 mm. |
| Load and axles | Load rating and single, tandem or triple axle. Standard UTV load is 1000 kg; standard ATV load is 500 kg. |
| Ramps and gates | Folding rear gate, upright ladder ramps, perforated ramps, mesh ramps. |
| Sides and body | Open flatbed with rails, box sides, cage or full mesh, tool box, tipping body. |
| Running gear | Tire and rim size, axle, leaf springs, fenders, and mechanical or hydraulic brake parts. |
| Coupler and jack | US, European and Australian style couplers and jockey wheels or crank jacks, chosen for your market. |
| Lighting and plugs | LED tail lights, side markers, and US, Australian or European plug and socket types. |
| Accessories | Winch, spare wheel, tool box, tie-down points, and for boats: rollers, slide bars, bunks and bow roller. |
| Finish | Hot-dip galvanized as standard on our flatbeds. Painted finishes such as black or red also appear in our catalog. |
| Packing | Wooden crate or sealed pallet, depending on how you ship. |
Availability of each option can depend on the model and size. We confirm brakes, certification and compliance for your destination in the quote.
How to customize your trailer in 5 steps
Define the job
List what you will carry: vehicle or machine model, its weight, width and length, and how often you will load it. Tracked machines need a different ramp from wheeled ones.
Pick a base model
Choose the closest family above. Starting from a standard layout keeps the design simple and the quote fast.
Draw your sketch
Use the template below. Even a hand drawing with dimensions is enough. Photos of a trailer you like are also helpful.
Confirm your market
Tell us the destination country or state so we can match the coupler, lighting, plugs and any brake or registration needs.
Review the drawing and quote
We reply with specifications and options. Check every dimension against your cargo, then approve to start production.
How to draw a custom trailer sketch
You do not need CAD. Draw a top view and a side view, then label the letters below. This is a sample flatbed top view.
- A Internal deck length (mm)
- B Internal deck width (mm)
- C Overall length including tongue (mm)
- D Tongue and coupler type
- E Ramp or gate position, width and length
- F Side height and side type: rail, box, cage or mesh
Also mark: axle count, wheel position, jack position, light position and any accessory such as a tool box, winch or spare wheel. Add the load you need in kg.
Copy this brief into your inquiry
Machine or cargo: ______ Weight (kg): ______ Width × length (mm): ______
Deck size A × B: ______ Load needed (kg): ______ Axles: single / tandem / triple
Ramp or gate: ______ Sides: rail / box / cage / mesh Brakes: yes / no / ask
Destination: ______ Coupler and plug type: ______ Quantity: ______
Sizing tips before you send your sketch
- Add working room: leave space around the cargo for tie-downs and for loading the widest part safely.
- Check the ramp: tracked machines, low-clearance vehicles and heavy loads need the right ramp width and angle.
- Match your tow vehicle: confirm its towing capacity and hitch type before you choose the trailer load.
- Check local rules: width, lighting, brake and registration requirements vary by country and state.
- Think about storage: a long tongue or tall sides may not fit your garage or yard.
From design to delivery
1. Engineering design
Layout balanced for appearance, stability and payload.
2. Premium materials
Hot-dip galvanized thick steel tubing for rust resistance and strength.
3. Configured components
Frame, tires, axle and leaf springs chosen for your load.
4. Quality inspection
Finishing, assembly testing and final inspection before shipment.
5. Shipping
Packaging options including wooden crates and sealed pallets.
6. After-sales support
One-to-one video guidance for installation and setup.
Custom trailer FAQ
Can you build a trailer to my exact size?
Yes. Deck size, overall size and load can be customized. Send a sketch with dimensions and the weight you need to carry.
Do I need a CAD drawing?
No. A hand sketch with dimensions, plus photos or a reference model, is enough. We turn it into a drawing for your approval.
What are the minimum order quantity and lead time?
They depend on the model and size, so we confirm both in your quote. Tell us your quantity when you inquire.
Can you match my country's coupler and plug type?
We list US, European and Australian style couplers, jacks and plugs in our catalog. Tell us your destination and we will confirm what applies.
Are brakes and certification available?
Brake parts such as mechanical and hydraulic units are in our accessory range. Brake, certification and registration needs depend on your market, so we confirm them per order.
Do you offer wholesale and OEM orders?
Contact us with your quantity and requirements for retail or bulk supply, and we will reply with options.
Ready to design your trailer?
Send your sketch, cargo details, destination and quantity. We will reply with a drawing, specifications and a quote.
Send my sketchBrowse trailers
