Electric Hydraulic Floor Crane 1.2 Ton
Electric Hydraulic Floor Crane 1.2 Ton - 900 KG is backordered and will ship as soon as it is back in stock.
Payment Way
Payment Way
After we Confirm the model, the deposit can be paid by paypal, or by T/T credit card transfer, etc.
Delivery and Shipping
Delivery and Shipping
Our products are sent from Qingdao port by default, before shipment, all machinery will be loaded with wooden crates and metal plates to prevent rust and corrosion, and then take photos and videos to customers to confirm, according to the agreed time to load the ship!
Electric Hydraulic Floor Crane 1.2 Ton
Towable Boom Lift
Q355 Hydraulic Motor, it can support 1-12Ton and fit for narrow base.
Description
Description
Electric Floor Crane 1.2 Ton Parameters:
Q255 Stronger manganese steel construction.Electric Floor Crane combines the advantages of a Stationary Crane and Propelled truck,providing the economy and efficiency of material handling,this equipment with following features:Low noise and no pollution;With adjustable support legs;Comfortable operation and convenient charge Flexible,reliable operation;Big wheels design,easy for outdoor use.
|
Model
|
RMEFL120
|
RMEFL90
|
|
Load Capacity
|
1200 KG
|
900 KG
|
|
Load Capacity of 1st arm
|
600 KG
|
450 KG
|
|
Load Capacity of 2nd arm
|
300 KG
|
250 KG
|
|
Max.Lifting Height
|
3520 mm
|
3550 mm
|
|
Rotation
|
/
|
Manual/Electric
|
|
Rotation Angle
|
/
|
240
|
|
Front Wheel Size
|
2x150x50
|
2x180x50
|
|
Balance Wheel Size
|
2x150x50
|
2x150x50
|
|
Driving Wheel Size
|
250*80
|
250*80
|
|
Lifting Motor
|
2
|
1.8
|
|
Accumulators
|
2*12V/80ah
|
4*6V/200ah
|
|
Battery level
|
24V/30A
|
24V/30A
|
|
Weight
|
750 KG
|
900 KG
|
More Safety:
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
What Is a Spider Crane?
A spider crane is a compact, self-propelled lifting machine mounted on rubber crawler tracks. Named for its four extendable outrigger "legs", it can fold to less than 800 mm wide to pass through standard doorways, then deploy for stable lifting in confined indoor or outdoor spaces where conventional cranes cannot operate.
🎁 Lifting capacity: 500 kg to 12,000 kg
🎁 Folded width: as narrow as 700–800 mm
🎁 Max lifting height: up to 25 meters
🎁 Customize more than 10 types of attachments
🎁 Outriggers: 4 independently adjustable legs
🎁 Power options: diesel (Kubota/Yanmar), electric
🎁 Control: wireless radio remote
🎁 Rotation: 360° continuous hydraulic slew
Contact WHATSAPP
Risenmega Spider Crane Specifications: Which Model Is Right for You?
Risenmega manufactures spider cranes from 1 ton to 12 tons, with arm lengths from 8 to 25 meters. Use the table below to match your lifting capacity and access requirements to the right model — each links directly to full technical specs and pricing.
| Model | Max Lift | Max Height | Dimensions | Grade IP | Engine | Power |
| 1 Ton spider crane | 1000KG | 8M | 2260*600*1470MM | IP-67 | Honda GX390 | 9.6KW |
| 2 Ton spider crane | 2000KG | 8M | 2780*710*1620MM | IP-67 | Honda 390CC | 10KW |
| 3 Ton spider crane | 3000KG | 10.5M | 3450*950*1700MM | IP-67 | Changchai EV80 | 12.0KW |
| 5 Ton spider crane | 5000KG | 16.5M | 4650*1400*2160MM | IP-67 | YN 25GB | 37KW |
| 8 Ton spider crane | 8000KG | 17.5M | 5010*1600*2200MM | IP-67 | YN 27GBZ | 58KW |
| 10 Ton spider crane | 10000KG | 20M | 5550*1850*2300MM | IP-67 | YN 27GBZ | 58KW |
| 12 Ton spider crane | 12000KG | 22M | 6050*1850*2300MM | IP-67 | Changchai | 65KW |
