Beyond Scissor Lifts: How Vertical Mast Lifts with Jibs Solve the "Up and Over" Problem Discover the Risenmega Vertical Lift with Jib (Tower Platform). Featuring upgraded Q355 high-yield steel, indoor/outdoor versatility (Wheeled/Crawler), and superior "up-and-over" reach capabilities.
In the world of aerial construction, facility maintenance, and warehousing, "height" is often the easy part. The real challenge is accessibility.
When you are facing narrow aisles, obstacle-cluttered floors, or work targets that are blocked by shelving and machinery, a standard scissor lift simply cannot reach. You need a machine that is compact enough to fit through a standard door but agile enough to reach over obstacles, not just up.
Enter the Vertical Lift with Jib, also known in the industry as the Tower Platform.
Whether you are navigating delicate indoor flooring or rugged outdoor terrain, this "Problem Solver" is designed to go where other machines can't. Today, we are diving deep into why this equipment—now upgraded with Q355 High-Strength Steel—is the essential addition to your fleet.
1. What is a Vertical Lift with Jib (Tower Platform)?
A Vertical Lift with Jib is a specialized Mobile Elevating Work Platform (MEWP) that combines the compact footprint of a vertical mast lift with the reach capabilities of an articulating boom.
Unlike a scissor lift, which only moves vertically, the Tower Platform features a telescopic mast topped with a movable Jib arm.
Vertical Mast: Raises personnel to the required working height.
The Jib: Provides horizontal outreach and angular movement, allowing the operator to reach over obstacles like assembly lines, piping, or retail racks.
According to our latest specifications, models like the RMWP11.2-8100 offer a Max Working Height of 11.2m and a Horizontal Reach of 3m, all while maintaining a compact footprint.
2. The Core Upgrade: Why Q355 Steel Matters
When working at heights of over 10 meters on a compact base, structural integrity is paramount. We have upgraded the core structure of our Tower Platforms to use Q355 High-Strength Structural Steel.
What is Q355 Steel?
Q355 is a low-alloy high-strength structural steel with a significantly higher yield strength compared to the standard Q235 steel often used in generic lifts.
The User Benefit:
Superior Rigidity: At full extension (e.g., 11.2m high with a 3m outreach), the Q355 steel minimizes the "sway" or deflection of the mast. This gives the operator a solid, stable feeling, boosting confidence and safety.
High Yield Strength: The upgraded steel can withstand higher stress loads without permanent deformation, ensuring the machine remains safe and operational for years, even in demanding rental environments.
Optimized Weight: By using stronger steel, we maintain a robust structure without excessive weight. For instance, the RMWP11.2 weighs just 2950kg, allowing it to be used on floors with specific load-bearing limits
3. Wheeled vs. Crawler: One Platform, Two Solutions
True versatility means adapting to the environment. Our Vertical Lifts with Jibs are available in two distinct chassis configurations to suit your specific "Indoor" or "Outdoor" needs.
Option A: The Wheeled Version (Indoor Specialist)
Designed for warehouses, shopping malls, airports, and factories.
Non-Marking Tires: Equipped with solid rubber tires (e.g., 381×127mm) that leave no black scuff marks on epoxy or tile floors.
Compact Agility: With an overall width of just 1.0m to 1.2m , these units can fit through standard doorways and into passenger elevators.
Tight Turning: The inner turning radius is as tight as 0.23m, making it perfect for maneuvering between narrow racking systems.
Option B: The Crawler Version (Outdoor & Rough Terrain)
Note: While our spec sheets highlight wheeled dimensions, we offer tracked configurations for challenging sites.
All-Terrain Access: Rubber tracks provide low ground pressure and superior traction on mud, grass, gravel, or uneven construction sites.
Stability: The crawler base offers a wider distribution of weight, ideal for outdoor glazing or facade work where the ground has not yet been paved.
4. Solving the "Access" Problem: Key Features
Why do project managers choose the Tower Platform over a boom lift? It comes down to specific problem-solving features.
A. The "Up and Over" Capability
Often, the target isn't straight up. It's up, and then over a barrier.
Jib Movement: The jib offers a 130° vertical range (+70°/-60°).
Clearance: The RMWP11.2 boasts an Up and Over Height of 7.89m.
Horizontal Reach: With up to 3 meters of horizontal reach, you can service machinery or change lightbulbs without moving the base of the machine into a hazard zone.
B. Precision Positioning
Once you are in the air, you need to get into the perfect spot.
Turret Rotation: The mast can rotate 345 degrees (non-continuous). This allows the operator to cover a massive working area without repositioning the chassis.
Proportional Controls: The joystick controls are proportional, meaning the speed of movement corresponds to how far you push the stick. This ensures smooth, jerk-free approach to delicate surfaces.
C. Efficiency Boosters
Drivable at Full Height: Operators can drive the machine while the platform is fully raised. This eliminates the time-consuming cycle of "lower-move-raise" when installing continuous features like conduit or ceiling panels.
AC Drive Motor: We utilize AC electric motors (e.g., 24V/0.9kW or 32V/3.3kW depending on model). These are maintenance-free (no carbon brushes), energy-efficient, and provide strong climbing power.
5. Technical Specifications Overview
To help you choose the right model, here is a breakdown of our popular RMWP series specs based on the technical data.
| Specification | RMWP11.2-8100 | RMWP10-7100 | RMWP13-7100 |
| Max Working Height | 11.2m | 8.0m (Platform) / ~10m Work | 10.65m (Platform) / ~12.6m Work |
| Max Platform Height | 9.2m | 8.0m | 10.65m |
| Horizontal Reach | 3.00m | 3.51m | 6.05m |
| Up & Over Height | 7.89m | N/A | N/A |
| Lifting Capacity | 200kg (2 People) | 200kg | 200kg |
| Machine Width | 1.00m | 1.00m | 1.20m |
| Machine Height (Stowed) | 1.99m | 1.98m | 1.98m |
| Power Source | 24V/240Ah Battery | 24V/220Ah Battery | 48V/260Ah Battery |
| Turret Rotation | 345° | 356° | 352° |
6. Safety and Maintenance: Built for the Long Haul
Safety is non-negotiable. The Risenmega Tower Platform is packed with active and passive safety systems.
Comprehensive Safety Suite
Pothole Protection: Automatic pothole guards deploy when the machine is elevated. If a wheel drops into a hole, the system stabilizes the chassis to prevent tipping.
Tilt & Overload Sensors: The machine constantly monitors the chassis angle (Max slope X-2.5°/Y-2.5°) and platform weight. If limits are exceeded, the Tilt Sensor Alarm and Overload Sensor will sound and restrict operation.
Emergency Descent: In the event of power loss, the Emergency Descent System allows the operator (or ground crew) to safely lower the platform. This is controlled via a dedicated knob or pull-cable.
Tubing Explosion-Proof System: Prevents the platform from free-falling if a hydraulic hose bursts.
Designed for Serviceability
Swing-Out Components: The chassis covers on both sides swing out, giving mechanics instant access to batteries and hydraulic systems for inspection.
Fault Diagnosis System: A display screen on the ground control panel provides error codes, allowing for rapid troubleshooting without external computers.
Maintenance-Free Battery: High-performance batteries require no water refilling and produce no pollution.
7. Conclusion: The Smart Choice for Complex Access
The Vertical Lift with Jib (Tower Platform) bridges the gap between the compact size of a scissor lift and the reach of a boom lift.
With the integration of Q355 high-strength steel, we have elevated the standard of durability and stability. Whether you choose the Wheeled version for your warehouse or the Crawler version for your job site, you are investing in a machine that is safer, stronger, and more versatile.
Ready to upgrade your fleet? Stop letting obstacles limit your productivity. Contact us today to discuss which Tower Platform model fits your project needs.
