Single Pad Glass Installation Vacuum Lifter 250-750 KG
Single Pad Glass Installation Vacuum Lifter 250-750 KG - 250 KG is backordered and will ship as soon as it is back in stock.
Payment Way
Payment Way
After we Confirm the model, the deposit can be paid by paypal, or by T/T credit card transfer, etc.
Delivery and Shipping
Delivery and Shipping
Our products are sent from Qingdao port by default, before shipment, all machinery will be loaded with wooden crates and metal plates to prevent rust and corrosion, and then take photos and videos to customers to confirm, according to the agreed time to load the ship!
Single Pad Glass Installation Vacuum Lifter 250-750 KG
Vacuum Lifter
Double system control, one vacuum system for working, and one for alternate.American THOMAS vacuum pump
Description
Description
Single Pad Glass Vacuum Lifter 250–750KG | Electric Glass Installation Lifter
Electric single-pad vacuum lifter for glass, marble, and metal panel installation. 360° rotation, 90° tilt, dual THOMAS vacuum pump, and a Panasonic digital pressure display — built on a Q245 steel frame for daily job-site use.
4 Capacities Available: 250 / 375 / 500 / 750KG
What Is the Single Pad Glass Vacuum Lifter Used For?
The Risenmega single pad glass vacuum lifter is an electric suction device that lifts and installs flat glass, marble, and metal panels weighing 250–750KG using one large vacuum pad. It replaces manual carrying teams during window, curtain-wall, and glass-door installation, letting one operator move and position panels without scratching or cracking the surface.
It runs on battery power, so it isn't tied to a compressor or shop air line — operators carry it directly to the installation point, attach the pad, rotate the panel into position, and lock it every 90° before releasing.
What Are the Technical Specifications of the RMBSC Series?
The RMBSC series covers four load capacities — RMBSC25 (250KG), RMBSC37.5 (375KG), RMBSC50 (500KG), and RMBSC75 (750KG) — all built on a Q245 steel frame with 360° rotation, 90° tilt, and 12V/20AH battery power. Pad size scales from 800×400mm to 1000×500mm depending on the model.
| Model | Load Capacity | Pad Size | Net Weight | Packing Size (mm) |
|---|---|---|---|---|
| RMBSC25 | 250 KG | 800×400mm | 62 KG | 850×450×400 |
| RMBSC37.5 | 375 KG | 1000×500mm | 72 KG | 1050×550×400 |
| RMBSC50 | 500 KG | 800×400mm | 56 KG | 850×450×400 |
| RMBSC75 | 750 KG | 1000×500mm | 66 KG | 1050×550×400 |
| RMSC120* | 1200 KG | 300mm (single round pad) | 39 KG | 1200×800×520 |
*RMSC120 is the higher-capacity model in the same Risenmega suction-cup lifter series, sold as a separate SKU — see comparison below.
What Safety Features Protect the Load During Lifting?
Every unit runs a dual vacuum system: an American THOMAS pump handles normal operation while a second pump stands by as backup if pressure drops. A Japan Panasonic digital display shows live vacuum pressure and battery charge, and the frame locks automatically every 90° of rotation to stop the load from swinging.
Dual THOMAS Pump System
A working pump plus a standby pump in the same housing, so the load stays held even if one system loses pressure.
Panasonic Digital Display
Live vacuum pressure and battery-fuel readout, with an alarm that warns the operator before pressure drops too low.
90° Auto-Lock Rotation
The frame rotates a full 360° and locks solidly every 90°, so panels can't drift out of position mid-lift.
What's the Difference Between the RMBSC Single-Pad Lifter and the RMSC120?
The RMBSC series uses a rectangular pad (800×400mm to 1000×500mm) for panels up to 750KG, while the RMSC120 uses one 300mm round pad rated to 1200KG. Choose RMBSC for standard window glass and RMSC120 when handling oversized curtain-wall panels or thick stone slabs.
- Capacity 250–750 KG
- Pad shape Rectangular
- Pad size 800×400 – 1000×500mm
- Net weight 56–72 KG
- Best for Windows, doors, standard panels
- Capacity 1200 KG
- Pad shape Round, single pad
- Pad size 300mm diameter
- Net weight 39 KG
- Best for Large curtain-wall / stone slabs
What Applications Is This Vacuum Lifter Designed For?
Fabricators use this lifter for tempered-glass window installation, glass curtain-wall assembly, shopfront and glass-door fitting, and marble, granite, or metal panel handling on site. The single-pad design suits panels too large to carry by hand but not wide enough to need a double-pad frame.
Window Glass
Tempered & laminated glass panels
Curtain Walls
Building facade glass installation
Doors & Shopfronts
Glass door and storefront fitting
Stone & Metal Slabs
Marble, granite & flat metal panels
Can the Lifter Be Customized for My Project?
Risenmega customizes this lifter's load capacity, walking speed, engine, plug standard, housing color, voltage, battery charging time, and hydraulic cylinder to match the buyer's country and job requirements. Confirm your exact configuration with a Risenmega sales engineer by email or WhatsApp before production begins.
How Is the Lifter Shipped, and What's the Typical Order Process?
Orders are confirmed with a 30% deposit by PayPal or bank transfer (T/T). Risenmega then builds the unit, packs it in a wooden crate with metal corner plates to prevent rust, and sends photos and video for buyer approval before loading. Machines ship FOB, CIF, or DDP from Qingdao port, with the option to consolidate several products in one container to cut freight cost.
Confirm & Deposit
Finalize model, options, and pay a 30% deposit via PayPal or T/T.
Production & QC
Unit is built to spec. [Insert your standard production lead time, e.g. "15–20 days"]
Crate & Confirm
Packed in a wooden crate with anti-rust metal plates; photos/video sent for your approval.
Ship From Qingdao
Loaded FOB, CIF, or DDP from Qingdao port on the agreed schedule.
Frequently Asked Questions
What is the load capacity range of this glass vacuum lifter?
What vacuum pump does it use?
Is CE certification available?
How is the lifter packed and shipped?
Get Your Custom Quote Today
Tell us your target load capacity, plug standard, and destination port — Risenmega will confirm configuration, price, and lead time within one business day.
