Battery-Powered Mobile Fork Stacker
Description
Description
Battery-Powered Mobile Fork Stacker with Wireless Remote Control
A compact, all-electric fork stacker that lifts up to 1,000 kg and reaches 1.3–2.0 m, so one person can move pallets, crates, drums, and machine parts onto shelving — without manual pumping or a fixed-position control panel.
- 700 kg rated working load, 1,000 kg mechanical maximum
- Handheld wireless remote — raise, lower, and stop from beside the load
- Four lift-height models on the same 1480 × 820 mm mobile base
Built for Everyday Warehouse and Workshop Lifting
Six reasons buyers choose this electric stacker over a manual hydraulic unit.
1,000 kg maximum load
Rated for 700 kg of continuous working load, with a 1,000 kg mechanical maximum and a 500 kg rated load once the forks reach full height.
Wireless digital remote
Every unit ships with a handheld digital remote, so the operator raises, lowers, and stops the forks from beside the load instead of a fixed panel.
48V / 12Ah battery pack
A sealed 48V, 12Ah battery drives the 700W lift motor through an 18-MOSFET controller for smooth, consistent lifting without hydraulic hand-pumping.
Four lift heights, one base
Choose 1.3 m, 1.6 m, 1.8 m, or 2.0 m of lift, all built on the same 1480 × 820 mm rolling base, to match the racking you already have.
Mobile, adjustable forks
Caster wheels let one person reposition the stacker across the floor, while the fork carriage adjusts to 160 mm fork width and 340 mm spacing for different pallets.
Built for OEM & export orders
Body color, operating voltage, AC plug type, and warning-label language can be customized for distributors and private-label buyers.
Choose Your Lift Height
All four models share the same footprint, motor, battery, and controller — the only difference is how high the forks travel. Select your lift height above in the product options, or use this guide to match a model to your racking.
Raised height above is the fork's lift travel; overall mast height (upright, forks down) ranges from 1.8 m on RM-1300 to 2.5 m on RM-2000 — see full table below.
Full Electric Stacker Specifications
| Machine type | Mobile fork stacker, adjustable forks |
| Fork width | 160 mm |
| Fork spacing | 340 mm |
| Maximum load | 1000 kg |
| Rated load (standard height) | 700 kg |
| Rated load (full lift height)* | 500 kg |
| Lift motor power | 700 W |
| Controller | 18-MOSFET digital lift controller |
| Battery | 48V / 12Ah rechargeable |
| Remote control | Included — wireless handheld digital remote |
| Base footprint (L × W) | 1480 × 820 mm |
| Fork carriage size (L × W, reference) | 1130 × 660 mm |
| Customization available | Body color, operating voltage, AC plug type, warning-label language |
*Rated load decreases at full lift height to maintain stability. Always operate within the rated load for the current fork height and follow the safety decals fitted to the mast.
| Model | Lift height | Overall height | Net weight | Gross weight | Wooden export crate (L × W × H) |
|---|---|---|---|---|---|
| RM-1300 | 1300 mm | 1800 mm | 202 kg | 234 kg | 1970 × 1070 × 450 mm |
| RM-1600 | 1600 mm | 2100 mm | 210 kg | 248 kg | 2270 × 1070 × 450 mm |
| RM-1800 | 1800 mm | 2300 mm | 214 kg | 255 kg | 2470 × 1070 × 450 mm |
| RM-2000 | 2000 mm | 2500 mm | 218 kg | 263 kg | 2670 × 1070 × 450 mm |
Where This Electric Stacker Earns Its Keep
This mobile fork stacker is built for the everyday lifting jobs that sit between a hand pallet truck and a full sit-down forklift: short lifts, tight aisles, and loads that need to go up onto a rack or bench rather than just across the floor.
Typical settings:
- Warehouses and distribution centers
- Light manufacturing and assembly lines
- Retail and grocery stockrooms
- Auto and equipment repair shops
- Loading docks and container yards
Common tasks
- Lifting palletized goods onto racking
- Moving drums, coils, and molds between workstations
- Loading and unloading vans and shipping containers
- Feeding stock up to mezzanine storage
Included with every unit
- Mobile fork stacker, fully assembled
- Wireless digital remote control
- Battery charger
OEM, Private Label & Export-Ready Customization
For distributors, resellers, and importers, RisenMega offers factory customization on this stacker line: body color, operating voltage (110V / 220V options), region-specific AC plug types, and warning-label language. This flexibility suits bulk orders that will be resold under your own brand, or shipped into a market with different electrical standards. Send us your destination country and order volume and our team will confirm customization options, lead time, and pricing.
Talk to Our Sales TeamPacked for Long-Distance Freight
Each stacker ships fully assembled inside a solid wooden export crate sized to its model, keeping the mast, fork carriage, and battery protected through ocean or air freight. Net and gross weights are listed per model in the comparison table above, so you can plan container loading and freight costs before you order.
Electric Stacker FAQ
What is a mobile fork stacker used for?
A mobile fork stacker lifts and moves palletized loads, crates, drums, and machine parts around a warehouse or workshop floor, then raises them onto racking or a workbench — a lighter, more maneuverable alternative to a full sit-down forklift.
How much weight can this stacker lift?
It carries a 1,000 kg mechanical maximum, with a 700 kg rated working load at standard lift height and a reduced 500 kg rated load once the forks reach full height. Always keep loads within the rated figure for the height you're lifting to.
Which lift height should I choose?
All four models share the same base and controls. Pick 1.3 m for low shelving, 1.6–1.8 m for standard pallet racking, or 2.0 m for tall racking, mezzanines, and truck or container loading.
Does it come with a remote control?
Yes. Every unit includes a handheld digital wireless remote, so the operator can raise, lower, and stop the forks from beside the load instead of standing at the machine's control panel.
How is the stacker powered, and is a charger included?
It runs on a 48V, 12Ah rechargeable battery through a 700W lift motor and an 18-MOSFET controller. A charger ships with every unit; actual run time between charges depends on load weight and duty cycle, so contact us for guidance specific to your shift pattern.
Can you customize the voltage, plug, or color for my country?
Yes. Operating voltage, AC plug type, body color, and warning-label language can all be adjusted at the factory for OEM, private-label, and export orders — send us your destination country and order volume for a quote.
How is the stacker packaged for shipping?
Each model ships in its own solid wooden export crate, sized to protect the mast, fork carriage, and battery during international freight. Crate dimensions and shipping weights are listed in the comparison table above.
Ready to Move More, Faster?
Tell us your required lift height and order volume, and our team will confirm lead time, customization options, and freight cost to your port.
