Product Details
Create Amazing Tables
Build amazing tables with full control over the columns, rows, spacing and more.
| Vehicle Capacity | 4500 kg |
| Working Frequency Range | 10–20 Hz |
| Drive / Control | Multi-frequency high-torque motor with micro-crystalline regulator |
| Transmission | Belt drive (low noise) |
| Power Supply | 380 V / 220 V / As required |
| Operating Temperature | −30 °C to +50 °C |
| Lift Height | ≈1100 mm |
| Net/Gross Weight | ≈785–825 kg |
Why Choose Risenmega
High Fidelity Simulation
With multi-frequency excitation (10–20 Hz), the Risenmega simulator reproduces authentic road vibrations and driver-reported conditions in a controlled, repeatable manner.
High Efficiency
Diagnostics that once required multiple road tests can now be completed within minutes, reducing customer waiting time and increasing service throughput.
High Safety
Equipped with mechanical and electrical interlocks, emergency stop controls, and soft/hard limit protection, it ensures full safety for operators and vehicles during testing.
Auto chassis road simulator head rotation 4.5 Ton
Regular priceUnit price /Unavailable
Auto chassis road simulator head rotation touch screen 4.5 ton
Regular priceUnit price /Unavailable
Auto chassis road simulator main unit head rotation
Regular priceUnit price /Unavailable
internal composition
-
Service Workshops & Repair Chains
Reproduce chassis noises, verify suspension or steering looseness, and record before/after video proof for customer communication.
-
Education & Training Centers
Demonstrate road profiles, component responses, and common fault scenarios in a safe, controlled setting.
Product Positioning
The Risenmega simulator belongs to the workshop-grade segment—designed for service centers and maintenance workshops seeking a cost-effective yet advanced solution for road-condition reproduction.
Unlike high-end laboratory-grade systems used by OEM R&D centers, this model focuses on practical diagnosis, ease of installation, and fast ROI, giving repair chains a professional testing capability without laboratory-level complexity or cost.
Core Technologies
Multi-Point Excitation
Four synchronized excitation platforms reproduce a variety of road profiles, including speed bumps, cobblestones, and continuous undulations, exposing faults that traditional test drives often miss.
Control and Synchronization
Driven by a multi-frequency, high-torque motor and quiet belt transmission, the simulator maintains stable motion and consistent output for accurate comparison of pre- and post-repair conditions.
Road Profile Capability
Customizable excitation sequences allow technicians to perform frequency sweeps or combined bump patterns, simulating diverse road surfaces and dynamic inputs.
Structure and Durability
The frame uses high-strength welded steel with laser-cut precision components and anti-corrosion coating. Wear-resistant bearings and polymer guide sliders ensure smooth operation and extended lifespan, even under continuous daily use.
Safety Architecture
Includes emergency stop, overload protection, electrical interlocks, leakage protection, and a 24 V safety control loop to minimize operational risks.
Delivery & Documentation
Each simulator package includes:
Two main working modules
Two support frames
Two stress-release modules
Delivered with user manual, certificate of conformity, packing list, and foundation drawings.
Summary
Warranty terms and spare-parts coverage are clearly defined in the contract, ensuring responsive after-sales support and minimized downtime.
The Risenmega Car Chassis Road Simulator empowers workshops to diagnose and verify chassis performance with laboratory-like accuracy at a practical price. Combining 4500 kg capacity, 10–20 Hz bandwidth, quiet operation, and comprehensive safety, it represents a new standard in professional suspension and noise diagnostics for service environments.
